Q-Front EDI is an excellent choice for your laboratory, providing both Grade 1 and Grade 2 water directly from tap water.
Adrona Q-Front EDI is a tap water system for general laboratory applications and inorganic analytical methods. Q-Front EDI systems are intended for use in laboratories with high daily pure and ultrapure water consumption.
Like other Adrona water purification systems, Q-Front EDI is available in Trace, HPLC, and Bio configurations to meet the specific needs of every laboratory and application.
If the feed water does not meet specifications, additional pre-treatment solutions are available.
| Parameters | Trace | HPLC | Bio |
|---|---|---|---|
| Grade 1 water resistivity at 25 °C | 18.2 MΩ x cm | 18.2 MΩ x cm | 18.2 MΩ x cm |
| Grade 1 water conductivity at 25 °C | 0.055 μS/cm | 0.055 μS/cm | 0.055 μS/cm |
| Grade 2 water resistivity at 25 °C | ≥ 10 MΩ x cm | ≥ 10 MΩ x cm | ≥ 10 MΩ x cm |
| Grade 2 water conductivity at 25 °C | ≤ 0.1 μS/cm | ≤ 0.1 μS/cm | ≤ 0.1 μS/cm |
| TOC level | < 10 ppb | < 5 ppb* | < 5 ppb* |
| Rnase | – | – | < 0.01 ng/mL |
| Dnase | – | – | < 4 pg/mL |
| Bacteria | < 0.01 CFU/mL | < 0.01 CFU/mL | < 0.01 CFU/mL |
| Endotoxins | < 0.15 EU/mL | < 0.15 EU/mL | < 0.001 EU/mL |
| Particles >0.22 μm | < 1/mL | < 1/mL | < 0.05/mL |
| Nominal flow, pure water (to storage tank) | 5 / 10 L/h | 5 / 10 L/h | 5 / 10 L/h |
| Dispense rate, ultrapure water | 1.5–2 L/min | 1.5–2 L/min | 1.5–2 L/min |
| Dimensions (WxDxH), cm | 35x39x54 | 35x39x54 | 35x39x54 |
| System weight, kg | 27 | 28 | 29 |
| Operating weight, kg | 30 | 31 | 32 |
*In appropriate operating conditions <2 ppb, otherwise normally <5 ppb
| Part number | Description | Comments |
|---|---|---|
| 10410 | Replacement pre-filters | |
| 10030 | Polishing+ module | |
| 10017 | Sterilization UV bulb | For Bio configuration |
| 10018 | UV photooxidation bulb | For HPLC and Bio configuration |
| 410175 | UV bulb | For automatic sanitization module |
| 10013 | 0.22 µm dispense microfilter, sterile | For Trace and HPLC configurations |
| 10120 | Ultrafilter | For Bio configuration |
| Part number | Description |
|---|---|
| 10327 | Water dispensing unit “Flow Point 3” |
| 13009 | Universal remote dispenser |
| 13005 | Water distribution module |
| 11015_Pro_tank_30l | Water storage tank “Pro”, 30 L with multipoint sensor |
| 10007L | Water storage tank “Comfort” 60 L with base, tap, and multipoint level sensor |
| 10027L | Water storage tank “Comfort” 100 L with base, tap, and multipoint level sensor |
| 10103 | UV sterilization module 24V |
| 10170 | External pre-filter set (carbonpp/ PP 1 μm) with manometer |
| 10171 | External pre-filter set (polyphosphate/carbonpp/1 μm) with manometer |
| 10175 | External input pressure reducer |
| 13007 | CO2 trap with microfilter |
| 10315 | Automatic sanitization module for tank |
| 12001 | Air filter for storage tank |
| 12002 | 0.22 μm bacteria air filter for storage tank |
| 410226 | AquaStop – Water leakage protection system |
| 10511 | Sanitization cartridge |
| 410143 | DQ/IQ/OQ/PQ documentation |
