When larger quantities of RO water are required, the RADIX system is a multifunctional solution for different applications. Depending on the model, the RO configuration can produce up to 250 L of RO water.
RADIX systems are designed as robust and reliable high-capacity purified water sources that require minimal maintenance while delivering exceptional output.
A typical setup includes the RADIX system, an atmospheric storage tank (equipped with an automatic UV sanitization module and CO2 trap), and a water distribution module.
Typical fields of application include but are not limited to:
| Parameter | 60 RO | 100 RO | 250 RO |
|---|---|---|---|
| Catalogue No. | RA-1001 | RA-1003 | RA-1005 |
| Capacity | 60 L/h | 100 L/h | 250 L/h |
| TDS rejection rate | ≥ 98.5% | ≥ 98.5% | ≥ 98.5% |
| Particles >0.22 μm | < 1/mL | < 1/mL | < 1/mL |
| Dimensions (WxDxH), cm | 33x72x77 cm | 33x72x77 cm | 33x94x77 cm |
| System weight, kg | 42 kg | 56 kg | 88 kg |
| Operating weight, kg | 52 kg | 63 kg | 97 kg |
| Part number | Description | Comments |
|---|---|---|
| 10420 | Pre-filter RADIPACK | |
| 10011 | Replacement sterilization UV bulb |
| Part number | Description | Comments |
|---|---|---|
| 10007 | Water storage tank “Comfort” | w/ base, tap and level switch, 60 L, dimensions (W*D*H): 42*42*85 cm |
| 10027 | Water storage tank “Comfort” | w/ base, tap and level switch, 100 L, dimensions (W*D*H): 45*45*112 cm |
| 10026 | Water storage tank “Comfort” | w/ level switch, 200 L, dimensions (W*D*H): 55*55*134 cm |
| 10025 | Water storage tank “Comfort” | w/ level switch, 300 L, dimensions (W*D*H): 66*66*144 cm |
| 13007 | Tank CO2 trap with microfilter | |
| 410110 | Water distribution pump 3 m3/h | |
| 10172 | UV loop sterilizer | |
| 10520 | Sanitization cartridge, Radix | NB Shipped separately due to shipment of dangerous cargo |
| 410226 | AquaStop | Water leakage protection system |
| 410143 | DQ/IQ/OQ/PQ documentation |
