TCN SUPER Natural Ovens are designed for precise maintenance of high temperatures with minimal variations. Ideal for various laboratory applications where reliable and controlled heat is necessary. Each model features a digital PID controller with a color touch screen display for easy parameter setting and monitoring. These devices come with the ability to store up to 8 programs with 8 steps each, plus an additional basic program with a single step.
The ovens are made of stainless steel with a large glass window on the door, allowing users to easily monitor internal processes without opening the door. All models include two or three wire shelves and come with a calibration report for 150°C. Additionally, the devices have safety classes with double digital temperature limiters and an additional fluid expansion limiter.
Available Models:
| Feature | TCN 50 SUPER | TCN 115 SUPER | TCN 200 SUPER |
|---|---|---|---|
| Power supply | 230 V | 230 V | 230 V |
| Capacity | 50 L | 115 L | 200 L |
| Maximum shelf load | 15 kg | 20 kg | 20 kg |
| Security class | 3.1 | 3.1 | 3.1 |
| Dimensions (WxHxD) | 690 x 584 x 635 mm | 810 x 704 x 750 mm | 940 x 774 x 905 mm |
| Internal dimensions | 400 x 330 x 420 mm | 520 x 450 x 495 mm | 650 x 495 x 640 mm |
| Display | Touch screen | Touch screen | Touch screen |
| Minimum distance between shelves | 50 mm | 50 mm | 50 mm |
| Frequency | 50 – 60 Hz | 50 – 60 Hz | 50 – 60 Hz |
| Warranty | 2 years | 2 years | 2 years |
| Working method | Natural convection | Natural convection | Natural convection |
| Name | TCN 50 | TCN 115 | TCN 200 |
| Number of shelves | 2 | 2 | 3 |
| Temperature homogeneity at 150°C | ±3.5 °C | ±3.5 °C | ±4 °C |
| Weight | 53 kg | 74 kg | 103 kg |
| Absorbed power | 1000 W | 1900 W | 2100 W |
| Temperature resolution | 0.1 °C | 0.1 °C | 0.1 °C |
| Overtemperature security | Electronic and electromechanical | Electronic and electromechanical | Electronic and electromechanical |
| Working temperature | +10 Ta … 300 °C | +10 Ta … 300 °C | +10 Ta … 300 °C |
| Heating time (150°C) | 16 min | 18 min | 20 min |
| Timer | 99 : 59 hh:mm | 99 : 59 hh:mm | 99 : 59 hh:mm |
| Temperature variation at 150°C | ±0.5 °C | ±0.5 °C | ±0.7 °C |
| Useful volume | 50 L | 115 L | 200 L |
