Adrona B300 is an ultrapure water purification system which requires an external water tank that uses tap water as feed water (tap water system). There are 3 variations available: B300 Trace, B300 HPLC, B300 Bio.
The B300 is a new integrated Grade 2/Grade 1 laboratory water system, replacing the customer-approved previous B30 model.
The B300 has completely new electronics and software, providing a number of additional features: large color touch screen, data logging capability, warning and alarm messages, a wide range of flow control options, the ability to connect multiple remote dispensers, Ethernet and USB interfaces, dispense report preparation, improved accuracy of conductivity and TOC measurements.
Feed Water Requirements:
| Parameter | Trace | HPLC | Bio |
|---|---|---|---|
| Catalogue No. | CB-3301 | CB-3303 | CB-3305 |
| Package incl. storage tank | CB-3301-P | CB-3303-P | CB-3305-P |
| Grade 1 water resistivity at 25 °C | 18.2 MΩ x cm | 18.2 MΩ x cm | 18.2 MΩ x cm |
| Grade 1 water conductivity at 25 °C | 0.055 μS/cm | 0.055 μS/cm | 0.055 μS/cm |
| Grade 2 water resistivity at 25 °C | >10 MΩ x cm | >10 MΩ x cm | >10 MΩ x cm |
| Grade 2 water conductivity at 25 °C | <0.1 μS/cm | <0.1 μS/cm | <0.1 μS/cm |
| TOC level | <10 ppb | <5 ppb* | <5 ppb* |
| Rnase | – | – | <0.01 ng/mL |
| Dnase | – | – | <4 pg/mL |
| Bacteria | <0.01 CFU/mL | <0.01 CFU/mL | <0.01 CFU/mL |
| Endotoxins | <0.15 EU/mL | <0.15 EU/mL | <0.001 EU/mL |
| Particles >0.22 μm | <1/mL | <1/mL | <0.05/mL |
| Nominal flow, pure water (to storage tank) | 10 L/h | 10 L/h | 10 L/h |
| Dispense rate, ultrapure water | 1.5–2 L/min | 1.5–2 L/min | 1.5–2 L/min |
| Volumetric dispense | 0.01–100 L** | 0.01–100 L** | 0.01–100 L** |
| Dimensions (WxDxH), cm | 32x56x58 | 32x56x58 | 32x56x58 |
| System weight, kg | 27 | 28 | 29 |
| Operating weight, kg | 30 | 31 | 32 |
| Part Number | Description | Comments |
|---|---|---|
| 10319 | Pre-filter set | |
| 10311 | Deionization Q with quick connectors | |
| 10031 | Polishing Q with quick connectors | |
| 10033 | Polishing QC with quick connectors | |
| 10037 | Polishing QH with quick connectors | |
| 10017 | UV sterilization bulb | For Bio configuration |
| 10018 | UV photo-oxidation bulb | |
| 10013 | 0.22 µm dispense microfilter, sterile | For HPLC configuration |
| 10120 | Ultrafilter | For Bio configuration |
| 410175 | UV bulb | For automatic sanitization module |
| Part Number | Description | Comments |
|---|---|---|
| 10427 | Water dispensing unit “Flow Point 4” | Designed for ultrapure (Grade 1) water dispense, adjustable in all dimensions, manual and/or volumetric dispensing, color graphic LCD display, full remote control for water purification system, compatible with Gradus, B300 and Connect LT systems, dimensions (WxDxH): 40x22x70 cm |
| 13009 | Universal remote dispenser | With 3 m supply hose with fixed stand without controller, suitable for any pressurized water system storing Pure (Grade 2) or RO water |
| 13005 | Water distribution module | |
| 11015 | Water storage tank “Pro”, 30 L with multipoint sensor | Opaque housing walls for protection against light, automatic UV sanitization module (optional), 25 L usable volume, level switch, gravity outlet, delivery pump option, multi-position level sensor option, dimensions: 39x44x60 cm, weight: 6.5 kg |
| 10007L | Water storage tank “Comfort” 60 L with base, tap and multi-point level switch | Automatic UV sanitization module (optional), delivery pump (optional), multi-position level sensor option, gravity outlet, compatible with all tap water systems, dimensions: 42x42x85 cm |
| 10027L | Water storage tank “Comfort” 100 L with base, tap and multi-point level switch | Dimensions: 45x45x112 cm |
| 10103 | UV sterilization module 24V | |
| 10170 | External pre-filter set (carbon/PP 1 μm) with manometer | Compatible with all tap water systems |
| 10171 | External pre-filter set (polyphosphate/carbon/PP 1 μm) with manometer | Compatible with all tap water systems |
| 10175 | External input pressure reducer | For tap water systems |
| 13007 | Tank CO2 trap with microfilter | |
| 10315 | Automatic sanitization module for tank | |
| 12001 | Air filter for storage tank | |
| 12002 | 0.22 μm bacteria air filter for storage tank | |
| 410226 | AquaStop | Water leakage protection system |
| 410144 | DQ/IQ/OQ/PQ documentation |
