The Adrona Crystal EX system is the economic model of a multi-purpose water purification system. Despite its affordable price, the Crystal EX system is capable of producing both Grade 1 and Grade 2 water. The system is based on reverse osmosis and ion exchange technologies optimized for the best quality. Crystal EX has an excellent price/performance ratio and very low operation costs.
There are 3 configurations available: Crystal EX Trace, Crystal EX HPLC, Crystal EX Bio.
Feed Water Requirements:
| Parameter | Trace | HPLC | Bio |
|---|---|---|---|
| Grade 1 water resistivity at 25 °C | 18.2 MΩ x cm | 18.2 MΩ x cm | 18.2 MΩ x cm |
| Grade 1 water conductivity at 25 °C | 0.055 μS/cm | 0.055 μS/cm | 0.055 μS/cm |
| Grade 2 water resistivity at 25 °C | >10 MΩ x cm | >10 MΩ x cm | >10 MΩ x cm |
| Grade 2 water conductivity at 25 °C | < 0.1 μS/cm | < 0.1 μS/cm | < 0.1 μS/cm |
| TOC level | < 10 ppb | < 5 ppb* | < 5 ppb* |
| Rnase | – | – | < 0.01 ng/mL |
| Dnase | – | – | < 4 pg/mL |
| Bacteria | < 0.01 CFU/mL | < 0.01 CFU/mL | < 0.01 CFU/mL |
| Endotoxins | < 0.15 EU/mL | < 0.15 EU/mL | < 0.001 EU/mL |
| Particles >0.22 μm | < 1/mL | < 1/mL | < 1/mL |
| Nominal flow, pure water (to storage tank) | 10 L/h | 10 L/h | 10 L/h |
| Volumetric dispense | – | – | – |
| Dimensions (WxDxH), cm | 40x35x55 cm | 40x35x55 cm | 40x35x55 cm |
| System weight, kg | 17 | 18 | 19 |
| Operating weight, kg | 24 | 25 | 26 |
| Part Number | Description | Comments |
|---|---|---|
| 10320 | Replacement pre-filter, Crystal EX | |
| 10310 | Replacement deionization module | |
| 10030 | Replacement polishing module | |
| 10017 | UV sterilization bulb | Bio configuration |
| 10018 | Replacement photooxidation UV bulb | HPLC and Bio configuration |
| 10013 | Replacement 0.22 µm dispense microfilter, sterile | Trace and HPLC configuration |
| 10120 | Replacement ultrafilter | Bio configuration |
| Part Number | Description | Comments |
|---|---|---|
| 13009 | Universal remote dispenser | With 3 m supply hose with fixed stand without controller, suitable for any pressurized water system storing Pure (Grade 2) or RO water. |
| 13005 | Water distribution module | |
| 13003 | Water storage tank “Pro”, 30 L | Without multipoint sensor. Opaque housing walls for protection against light. 25 L usable volume. Gravity outlet. Delivery pump option. Dimensions: 39*44*60 cm |
| 10007 | Water storage tank “Comfort” 60 L with base, tap and multi-point level switch | Automatic UV sanitization module (optional). Delivery pump (optional). Multi-position level sensor option. Gravity outlet. Compatible with all tap water systems. Dimensions: 42*42*85 cm |
| 10170 | External pre-filter set (carbon/PP 1 μm) with manometer | Compatible with all tap water systems. |
| 10171 | External pre-filter set (polyphosphate/carbon/PP 1 μm) with manometer | |
| 10175 | External input pressure reducer | For tap water systems. |
| 13007 | Tank CO2 trap with microfilter | |
| 10315 | Automatic sanitization module for tank | |
| 12001 | Air filter for storage tank | |
| 12002 | 0.22 μm bacteria air filter for storage tank | |
| 410226 | AquaStop | Water leakage protection system |
| 10103 | UV sterilization module 24V | |
| 410143 | DQ/IQ/OQ/PQ documentation |
